OEM ODM Acrylic Filter Bag cage Dust Collector Cages

Brand Name : 17s

Model Number : customized

Certification : ISO

Place of Origin : China

MOQ : negotiable

Price : negotiable

Supply Ability : TBD

Delivery Time : TBD

Packaging Details : polybag and pallets for bags and steel crates for cages

Cage Material : Stainless Steel,Carbon Steel, Galvanized Wire,

Cage Finish Treatment : Silicon Coating, Zinc Coating, Electrophoresis Coating

Pack : Steel Crate

Size : customized

MOQ : Negotiable

Cage Top Cap : Ordinary Cap, Venturi Top, Mikopul Cap, Hook Top, Ring Top, ETC

Cage Joint : Twist Lock, Finger Lock, Slide Lock, Global Joint Lock

Cage Style : Round, Special Design

Contact Now

Round Acrylic Dust Filter Bag Cage Bag House Acrylic Normal Bag Cage Acrylic Filter Bag Cage

1. Specification
Cages are frameworks for bags, which is the bone of bags and supports the bags running. Both bags and cages are the most important element for bag houses. Star Cages are welded by special supporting rings (Spiders). We have own stretch line, cut line, weld line, coating line and check equipment. Providing a wide range of star filter cages for bag house collector, which improve the performance, efficiency and bottom line of the bag house dust collector and flue.

2. Procedure of cage making

1	stretch line	streth 6 or 6.5 raw wire to roll diameters wires for cages, normally 3mm, 3.5mm and 4mm,
2	cut line	cut roll wires to fixed length based on cage sizes
3	weld body	weld vertical wires and suppoting ring together
4	weld top and bottom cap and venturi	weld top and bottom cap to cage, venturi if necessary
5	coating	silicon or zinc coating if necessary
6	inspect and fix	inspect weld loose, burs, coating etc and fix
7	pack	put cages into steel crates

OEM ODM Acrylic Filter Bag cage Dust Collector Cages

3. Cage construction

Optional Material: carbon steel, galvanized wire, stainless steel
Cage Diameter: customized
Cage Finish Treatment: silicon coating, zinc coating, electrophoresis coating
OEM ODM Acrylic Filter Bag cage Dust Collector Cages
Cage Head: normal top cap, venturi top cap, split top (Mikropul) cap, wires bent (hook) top, enlarged top ring etc

Cage Joint: cages were too long or top space of bag house was not enough, we suggest make cages in sections with joint like below

OEM ODM Acrylic Filter Bag cage Dust Collector Cages

Cage pack
